PCBA, Hast Board & Burn In Board Fabrication
- We are creating specialized circuit boards designed to withstand highly accelerated stress testing.
- It is crucial for evaluating the reliability and robustness of electronic components under extreme conditions.
- Hast testing helps identify potential weaknesses in electronic systems, allowing for enhancements in design and manufacturing processes.
| No. Of Layers | 4-8 |
|---|---|
| Board Materials | BT-Resin, Nelco 4000 & Polymide |
| Board Thickness | 0.06″ |
| Board Thickness Tolerance | ±10% |
| Minimum Outer Line Width | 4 mil |
| Minimum Inner Line Width | 3.5 mil |
| Minimum Outer Space Trace | 4 mil |
| Minimum Inner Space Trace | 4 mil |
| Minimum Inner Space Trace | 8 mil |
| Layer-to-Layer Registration | 6 mil |
| Minimum Component Pitch | 0.02” |
| Minimum Hole Size | 6 mil |
| Final Finishing | Immersion Gold Hard Gold |
| Silk Screen | White Gold |
| Operating Temperature | 150°C |
