Datasheet
| Part Number | Series | Fastening Type | Wheel Diameter | Tread Width | Wheel Type | Mount Height | Swivel Radius | Bearing Type | Brake Type | Capacity |
|---|---|---|---|---|---|---|---|---|---|---|
| ES4X2MOR | E-Line Series | Swivel Caster | 4.000, 5.000, 6.000, 8.000 Inch | 2 Inch | Mold-on Rubber Thermo-Rubber (Flat), Thermo-Rubber (Donut), Thermo-Urethane(Maroon/Grey), Solid Polyurethane K, Polypropylene HD, Phenolic, Mold-on Poly | 5 5/8 Inch | 3 3/8 Inch | Roller | None, Tread Lock Brake, 5-Inch Cam Brake, Total Lock Brake | 400 Ibs |
| ESRS4X2MOR | E-Line Series | Sealed Swivel Caster | 4.000, 5.000, 6.000, 8.000 Inch | 2 Inch | Mold-on Rubber Thermo-Rubber (Flat), Thermo-Rubber (Donut), Thermo-Urethane(Maroon/Grey), Solid Polyurethane K, Polypropylene HD, Phenolic, Mold-on Poly | 5 5/8 Inch | 3 3/8 Inch | Roller | None, Tread Lock Brake, 5-Inch Cam Brake | 400 Ibs |
| ER4X2MOR | E-Line Series | Rigid Caster | 4.000, 5.000, 6.000, 8.000 Inch | 2 Inch | Mold-on Rubber Thermo-Rubber (Flat), Thermo-Rubber (Donut), Thermo-Urethane(Maroon/Grey), Solid Polyurethane K, Polypropylene HD, Phenolic, Mold-on Poly | 5 5/8 Inch | – | Roller | None, Tread Lock Brake | 400 Ibs |
Description
- Weight capacities up to 1,250 lbs
- Variety of 4″, 5″, 6″ & 8″ diameter wheels
- All wheels have 2″ tread width
- Double ball raceways for smooth swiveling action
- 1/4″ thick steel leg construction
- 5/8″ diameter permanent rivet kingpin
- RoHS compliant industrial zinc finish for corrosion resistance
- 1/2″ hollow axle with grease zerk and lock nut
- 4 brake options: compatible on both swivel and rigid casters
- NSF listed on select models
Tread Types
Thermo-Urethane
- Polyurethane tread mechanically locked to polypropylene core
- Load capacity to 800 lbs/ea
- Maroon tread on grey core; other color options available by special order. Contact factory for details.
- Attractive, all-purpose wheel
- Good in wet applications; resistant to most chemicals
Mold-On Rubber
- Rubber bonded to cast iron core
- Load capacity to 600 lbs/ea
- Quiet, shock-absorbing ride
Thermo-Rubber
- Non-marking tread
- Load capacity to 600 lbs/ea
- Good floor protection
- Quiet, shock-absorbing ride
- Available in Flat or Donut tread shapes
- Good in wet environments; resistant to most chemicals
Polykat Thermo-Urethane
- Premium Polyurethane on Glass-reinforced Polypropylene core
- High load capacity to 1,200 lbs/ea; high impact strength
- Maintenance free, sealed precision ball bearings
- Excellent roll-ability and floor protection
- Good in wet applications; resistant to most chemicals
Polypropylene HD
- Lightweight, economical wheel
- Good load capacity to 900 lbs/ea
- Excellent impact strength
- Superior in wet environments; resistant to most chemicals
Phenolic
- High load capacity to 1,250 lbs/ea
- Hard tread, rolls easily
- Excellent impact strength
- Abrasion resistant
Mold-On Poly
- Polyurethane bonded to cast iron core
- High load capacity to 1,250 lbs/ea
- Good roll-ability and floor protection
Cast Iron
- Solid 1-piece construction
- High load capacity to 1,250 lbs/ea
- Hard tread, rolls easily
- Excellent impact strength
- High temperature industrial use up to 600°F – must use optional steel retainer washers (SW).
Options
Brake Options
- Wheel Face Brake
- Tread Lock Brake
- Short Pedal – 5″ Length Cam Brake
- Long Pedal = 7″ Length Cam Brake
- Total Lock Brake
Thread Guard Options
- Metal Thread Guards
- Plastic Thread Guards
Bearing Options
- Delrin®
- Polykat Precision Ball
- Roller Standard
- Pedestal Precision Ball
Retainer Washer Options
- Standard: Plastic Retainer Washer
- Optional: Steel Retainer Washer
Sealed Raceway Options
Rubber raceway seals keep dirt out and lubricant in for longer caster life.
Features
- Medium Duty Caster
